How does Steam Turbine Work ?

How does Steam Turbine Work ?


This video lecture explains the basic working principle behind steam turbines. Here energy transfer from fluid to solid is explained in a logical manner. Concepts like degree of reaction, impulse turbine , reaction turbine and parson turbine




Photos of Huge Ship being built in factory step by step ( Harland and Wolff )

These are Photos of Huge Ship being built in  ( Harland and Wolff ) factory step by step


A map of the Harland and Wolff shipyards showing the different departments.




Working on a turbine in the engineering workshop



Workers fitting the deck on a large tanker on 22.4.1964 see the riveters' hydraulic power lines snaking all over the place, and many tripp



Men working in the foundry, pouring molten steel. The are wearing ordinary clothes today there is much more protection from the dangerous



Pattern makers carrying a wooden pattern. This was used to make a copy in steel, for a part of a ship.






A steam-powered floating crane lifting a large object on the quay.




Platers fitting a steel plate onto the deck of a ship. Later it will be riveted and welded into place to make it watertight.




A ship's deck takes shape as platers lay down plates. These will be bolted into place before being riveted and welded.




A riveter using a hydraulic chisel to smooth off the edge of a rivet. More holes all over the plate will be filled with rivets until the who




Circular platers fitted plates to curved areas such as funnels and masts. Here they are fitting an outer plate to the stern of a ship. Late




The manager. Some were nicknamed 'The Hat', or 'Air Raid' workers kept busy when the manager was spotted!




The engineering workshop. Diesel engines are being built at the left (top left is one almost complete) and in the centre of the workshop is




A ship's gearbox precision engineering on a grand scale!




A drive chain just like a bike chain, but much bigger! This does the same job, transferring power from the engine to the propeller. On a




An electrician working with a lathe.




The joiners' workshop. A passenger ship included hundreds of cabins, each with doors and beds to be made.




Upholsterers working on two staircases.




The pattern making workshop. Here the draughtsmen's drawings were scaled up into full sized chalk shapes on the floor, then made into woode




An upholsterer. Women worked here and in the drawing office, but nearly all the shipyard workers were men.




An upholsterer preparing patterned material by marking it out with chalk.




The pattern making workshop, where the draughtsmen's drawings were scaled up into full sized chalk shapes on the floor, then made into woode




The Harland and Wolff drawing office in the early 20th century.



Beneath a ship, the painters have been working. The paint protects the steel from rusting under the water.




The tanker 'Esso Ulidia' under construction in 1970.




The tanker 'Esso Ulidia' on its sea trials. The painters had not finished painting the superstructure and had to finish the job at sea.




Workers on board the 'Esso Ulidia', 1970.





A section of the English Star being lifted into place beside its sister ship which was being built next to it.



A section of a ship's hull is lifted into place, with workers looking on. One of them warms his hands by the brazier.



Workers dwarfed by the huge hull of a ship in dry dock, showing the propeller, rudder and keel blocks.




Workers finishing brass propellers in the workshop, 12.3.1959.




















Thursday, March 20, 2014

How Bottles are Filled ( Vacuum Filling Machine ) ?

How Bottles are Filled

( Vacuum Filling Machine )



Tank Chair ( wheelchair ) ! ( Machines )

 Tank Chair ( wheelchair ) !



Tank Chair is a custom off-road wheelchair that can go anywhere outdoors. Tank Chair conquers streams, mud, snow, sand, and gravel, allowing you to get back to nature. Using rubber tracks and high-torque electric motors, Tank Chair will take you anywhere and back.










Gorgeous Stainless Steel Sculptures By Kevin Stone ( Machines )

Gorgeous Stainless Steel Sculptures

By Kevin Stone


Chilliwack, British Columbia-based Kevin Stone specializes in creating gargantuan, one-of-a-kind stainless steel sculptures. His towering bald eagle, called "Power and Authority," stands an astounding 20 ft high and has a massive 31 ft wingspan. He also completed an 85 feet long mirror polished stainless steel sculpture, the "Imperial Water Dragon." For almost two years, working seven days a week, he designed and created this 6000 lb, 12 ft high, 14 ft wide and 35 ft long dragon with two massive coils. It was made for River Rock Casino Resort in Richmond to celebrate the Year of the Dragon.
